| Power ： Conventional Power |
| Manufacturer：Joint Venture/Imported |
| Bucket |
| Backhoe |
| Tonnage (tons) 48 |
| Operating Weight (kg) 48162 |
| Bucket Capacity (m³) 2.6 |
| Boom Length (mm) 7000 |
| Dipper Length (mm) 3000 |
| Performance |
| Swing Speed (rpm) 8.9 Swing Torque (Nm) 166.3 Travel Speed (km/h) 5.1/3.1 Bucket Digging Force (kN) 284 Stick Digging Force (kN) 235 Maximum Traction Force (kN) 333.4 |
| Power System |
| Engine Model: VOLVO D13F |
| Rated Power (kW/rpm): 270/1800 |
| Maximum Torque (Nm): 1836/1400 |
| Hydraulic System |
| Main Pump Max Flow (L/min) 2*355 |
| Working Hydraulic System (MPa) 32.4 |
| Travel Hydraulic System (MPa) 32.4 |
| Swing Hydraulic System (MPa) 25.8 |
| Fluid Capacities |
| Fuel Tank (L) 680 |
| Engine Oil Capacity (L) 55 |
| Coolant (L) 60 |
| Main Dimensions |
| Transport Width (mm) 3440 Cab Height (mm) 3280 Upper Structure Width (mm) 2990 Track Ground Length (mm) 4470 Track Total Length (mm) 5470 Track Shoe Width (mm) 600 Track Gauge (mm) 2740 Minimum Ground Clearance (mm) 515 Counterweight Ground Clearance (mm) 1210 |
| Rear Swing Radius (mm) 3880 |
| Working Range |
| Maximum Digging Radius (mm) 11817 |
| Maximum Digging Depth (mm) 7478 |
